P780-1 | 706 kVA to 780 kVA Diesel Generator | Perkins Engine

Medium Range 225 – 938 kVA P780-1

Request A Price Find Dealer

Size A Generator

Build Your Own Generator

Key Specs

Minimum Rating: 706 kVA / 565 kW; 706 kVA / 565 kW

Maximum Rating: 780 kVA / 624 kW; 780 kVA / 624 kW

Emissions/Fuel Strategy: Fuel Optimised; Fuel Optimised

P780-1
Change model

Overview

350 - 938 kVA Range

The new 350 - 938 kVA industry leading power range is the result of a continued focus on performance, durability and serviceability combined with the most advanced production methods to deliver power you can trust.

Features At A Glance

Displaying 1-6 of 6

The Story

The 350 - 938 kVA range from FG Wilson is designed by our expert engineers to deliver power you can trust. With an enhanced choice of power nodes, this range is engineered for optimum performance in diverse applications. Expert Design� Trusted Power

FG Wilson Diesel Engine

The Perkins 2000 Series offers excellent performance from the well-proven 6 cylinder 13, 15 & 18 litre in-line diesel engines. Developed from a proven heavy-duty industrial base, the engine offers superior performance and reliability. Its premium design ensures economic and durable operation, low emissions and advanced performance and reliability.

Alternator

Benefiting from a choice of leading alternators, the range incorporates the FG Wilson alternator as standard whilst offering a Leroy Somer optional upgrade.

PowerWizard 1.1+

The FG Wilson PowerWizard range of digital control panels, combine straightforward menu navigation with advanced metering and protection technology. They are used in automatic mains failure applications in conjunction with transfer panels. Our PowerWizard range allows you to monitor and control your generator set with ease, whilst ensuring your unit operates within safe parameters and provides important diagnostic information when needed.

Testing & Validation

Fully prototype tested with certified torsional vibration analysis available

World Wide Product Support

FG Wilson manufactures product in the following locations: Northern Ireland • Brazil • China • India With headquarters in Northern Ireland, FG Wilson operates through a Global Dealer Network.

Benefiting from a choice of leading alternators, the range incorporates the FG Wilson alternator as standard whilst offering a Leroy Somer optional upgrade.

Fully prototype tested with certified torsional vibration analysis available

FG Wilson manufactures product in the following locations: Northern Ireland • Brazil • China • India With headquarters in Northern Ireland, FG Wilson operates through a Global Dealer Network.

Specifications Standard Equipment Optional Equipment

Product Specifications for P780-1

Generator Set Specifications

Minimum Rating	706 kVA / 565 kW 706 kVA / 565 kW
Maximum Rating	780 kVA / 624 kW 780 kVA / 624 kW
Emissions/Fuel Strategy	Fuel Optimised Fuel Optimised
50 Hz Prime	706 kVA / 565 kW 706 kVA / 565 kW
50 Hz Standby	780 kVA / 624 kW 780 kVA / 624 kW
Frequency	50 Hz 50 Hz
Speed	1500 RPM 1500 RPM
Voltage	230-400 Volts 230-400 Volts

Engine Specifications

Engine Model	Perkins® 2806A-E18TTAG4 Perkins® 2806A-E18TTAG4
Bore	145 mm (5.7 in) 145 mm (5.7 in)
Stroke	183.0mm (7.2 in) 183.0mm (7.2 in)
Governor Type	Electronic Electronic
Displacement	18.1l (1104.5 cu. in) 18.1l (1104.5 cu. in)
Compression Ratio	14.0:1 14.0:1

P780-1 Standard Equipment

Engine

Air Cleaner

Lube oil drain valve

Engine filled with lubrication oil

High Coolant Temperature Shutdown

Low Oil Pressure Shutdown

Engine mounted battery charging alternator

Cooling

Package mounted radiator

Radiator fan and charging alternator guards

Coolant Drain Valve

Cooling System filled with Coolant mix

Exhaust

Exhaust flange outlet

Exhaust bellows and gasket

Fuel

8 Hr Fuel Tank

BSP Fuel Sockets
